Khoom Piav Qhia S Hom Fin Tube| Square Finned Tube: Square fins yog welded mus rau ib puag ncig puag ncig raj. S Hom Fin Tube Cov Khoom Siv: Carbon Steels, Alloy Steels, Stainless Hlau, Nickel Alloys, thiab lwm yam S Hom Fin Tube Loj: Base Tube OD: 31.8 - 57 hli Fin Loj: 60 - 145 hli Fin Pitch: 12. {4}}...

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

Khoom Description

S Type Fin Tube| Square Finned Tube:

Square fins yog welded mus rau ib puag ncig puag ncig raj.

S Hom Fin Tube Khoom siv:

Carbon Steels, Alloy Steels, Stainless Hlau, Nickel Alloys, thiab lwm yam

S Hom Fin Tube Loj:

Base Tube OD: 31.8 - 57 hli

Fin Size: 60 - 145 hli

Fin Pitch: 12.5 - 50 hli

Tube Length: 1 - 10 hli

Fin Thickness: 2 - 3 hli

S Hom Fin Tube Fields ntawm daim ntawv thov:

Economisers, Biolers, Kub Exchangers. Feem ntau siv nyob rau hauv cov dej tsis-corrosive gas, tsawg heev tsis kam mus rau roj ntws thiab cov roj ncaj nraim inhibit fouling thiab yooj yim tu.

S Type Fin Tube Manufacturing txheej txheem:

Square lossis rectangular fins yog welded rau ntawm lub hauv paus steel raj.

S Hom Fin Tube Qhov Zoo:

1) Lub square finned tube economizer es tsis txhob ntawm lub raj du economizer tuaj yeem ua rau thaj chaw sib pauv cua sov, txo cov raj, ua kom cov roj ntws ntws, txo cov roj flue tshaj tawm thiab hnav.

2) Lub raj square finned tuaj yeem ua rau "ob chav H" hom finned raj nrog ob lub raj, uas muaj cov qauv zoo rigidity thiab tuaj yeem siv rau hauv cov tsev txhab nyiaj ntev.

3) Lub square finned tube economizer yog npaj ua ntu zus. H-hom finned raj faib qhov chaw mus rau ntau qhov chaw me me, uas muaj kev ua haujlwm ntawm kev sib npaug thiab txo qhov hnav zoo heev.

4) Qhov zoo tshaj plaws soot tshuab tuaj yeem tau txais los ntawm kev tsim cov kab ncaj nraim ntawm ob sab ntawm H-shaped fins.

5) Lub square finned tube qhov chaw yog compact, tag nrho qhov hnyav yog txo, thiab tus nqi txo

6) Kev txuag hluav taws xob thiab kev siv hluav taws xob tsawg: lub tshuab hluav taws xob siv rau lub tshuab hluav taws xob tuaj yeem txo cov cua sov ntawm cov pa tawm ntawm lub tshuab hluav taws xob tsawg kawg yog 2/3, thiab tsuas yog haus 2-4kw ib tuj ntawm chav.

7) Kev ua haujlwm yooj yim thiab kev saib xyuas; Kev txuag hluav taws xob: lub tshuab hluav taws xob tau sib sau ua ke tag nrho, nrog tsawg dua qhov txav, qauv yooj yim thiab yooj yim installation. Qib siab ntawm automation, kev ua haujlwm yooj yim thiab kev saib xyuas, tuaj yeem txo cov neeg ua haujlwm.

S Type Fin Tube Drawing
