Thick Wall Steel Yeeb Nkab

Ncaj seam welded yeeb nkab, nrog kub-kuav los yog txias-kuav los tiag steel phaj los yog steel sawb coil vuam ua los ntawm steel yeeb nkab nyob rau hauv cov khoom siv vuam rau ncaj seam vuam kom tau cov yeeb nkab yog hu ua ncaj seam welded yeeb nkab.

Xa kev nug

Tsham tam sim no

Khoom Taw qhia

Thick Wall Steel Tubing Description

Thick-walled welded yeeb nkab cov txheej txheem tsim khoom tuaj yeem muab faib ua txias-kho, txias-kuav los tiag thiab kub dov peb txoj hauv kev, cov khoom siv ntawm cov yeeb nkab steel 10 #, 20 #, 35 #, 45 # hu ua cov yeeb nkab zoo tib yam, 16Mn nruab nrab ntawm cov yeeb nkab steel zoo tib yam thiab cov yeeb nkab steel hlau hu ua qis alloy steel yeeb nkab, cov khoom siv ntawm cov yeeb nkab steel 27SiMn, 12Cr1MoV, 10CrMo910, 15CrMo, 35CrMo, nrog rau cov yeeb nkab steel hlau sib sau ua ke hu ua alloy steel yeeb nkab.

UA SAWL PIPES

Sab nraud txoj kab uas hla: Φ508mm- 1118mm (20"- 44")

Phab ntsa Thickness: 6.{1}}.4mm 1/4"-1"
Cov Qauv Zoo: API, DNV, ISO, DEP, EN, ASTM, DIN, BS, JIS, GB, CSA
Ntev: 9-12.3m (30'- 40')
Qib: API 5L A-X90, GB / T9711 L190-L625

JCOE SAWL PIPES

Sab nraud txoj kab uas hla: Φ406mm- 1626mm (16" - 64")
Phab ntsa Thickness: 6.0- 75mm (1/4" - 3")
Cov Qauv Zoo: API, DNV, ISO, DEP, EN, ASTM, DIN, BS, JIS, GB, CSA
Length: 3-12.5m (10'- 41')
Qib: API 5L A-X100, GB / T9711 L190-L690

Kev kam rau sab nrauv thiab phab ntsa Thickness

Hom	Txuj
Hom	SY/T 5040-2000	SY/T 5037-2000	SY/T9711 1-1977	ASTM A252, ASTM A252	AWWA C200-97	API 5L PSL1
Tube kawg OD sib txawv	±0.5%D	±0.5%D	-0.79mm -+2.38mm	<±0.1%T	<±0.1%T	± 1.6 hli
Phab ntsa thickness	±10.0%T	D<508mm, ±12.5%T	-8%T-+19.5%T	<-12.5%T	-8%T-+19.5%T	5. 0mm
Phab ntsa thickness	±10.0%T	D>5 08 hli, ± 10.0% T	-8%T-+19.5%T	<-12.5%T	-8%T-+19.5%T	T Ntau dua lossis sib npaug rau 15.0mm, ± 1.5mm

Chemical Composition thiab Mechanical Properties of Thick Wall LSAW Steel Pipe

Txuj	Qib	Tshuaj muaj pes tsawg leeg (max)%					Mechanical Properties (min)
Txuj	Qib	C	Mn	Si	S	P	Yield zog (Mpa)	Tensile zog (Mpa)
TS EN 10025	S235 JR	0.17	1.4	-	0.035	0.035	235	360
	S275 JR	0.21	1.5	-	0.035	0.035	275	410
	S355 JR	0.24	1.6	-	0.035	0.035	355	470
TIAB SA 17100	ST 37-2	0.2	-	-	0.050	0.050	225	340
	ST 44-2	0.21	-	-	0.050	0.050	265	410
	ST 52-3	0.2	1.6	0.55	0.040	0.040	345	490
JIS G3101	SIB 400	-	-	-	0.050	0.050	235	400
JIS G3101	SIB 490	-	-	-	0.050	0.050	275	490
API 5L PSL1	A	0.22	0.9	-	0.03	0.03	210	335
	B	0.26	1.2	-	0.03	0.03	245	415
	X42	0.26	1.3	-	0.03	0.03	290	415
	X46	0.26	1.4	-	0.03	0.03	320	435
	X52	0.26	1.4	-	0.03	0.03	360	460
	X56	0.26	1.1	-	0.03	0.03	390	490
	X60	0.26	1.4	-	0.03	0.03	415	520
	X65	0.26	1.45	-	0.03	0.03	450	535
	X70	0.26	1.65	-	0.03	0.03	585	570

Thick Wall Welded Yeeb Nkab

lsaw pipe welded steel pipe

Heavy Wall Steel Tubing Supplier-GNEE Group

thick wall pipe supplier

Hais txog GNEE

200+ cov neeg ua haujlwm
16+ xyoo dhau los
16 steel yeeb nkab ntau lawm kab: 5 galvanized yeeb nkab ntau lawm kab, 3 tuab-walled yeeb nkab ntau lawm kab, 2 stainless hlau yeeb nkab ntau lawm kab, 3 anti-corrosion yeeb nkab ntau lawm kab, 1 yeeb nkab fittings ntau lawm kab, 2 steel yeeb nkab ua kab ntau lawm
8000+ Cov neeg siv khoom thoob ntiaj teb
Sab saum toj 10 zoo-paub steel yeeb nkab mov saw pawg hauv Suav teb
